Lighting-UL Certified LED Industrial Linear lighting / Swordfish
Features:
- Wide power range from 18W to 100W
- Luminaire efficiancy up to 140lm/w
- Widely Voltage: 100-277VAC and 141-392 VDC
- Different beam angle for optional(Narrow, Medium,Wide)
- Copper-free Aluminium enclosure, high impact resistance tempered glass lens.
- All exposed fasteners with quality stainless steel 316
lmportant Specification:
Certificate |
UL , CE, RoHS |
IP Grade |
IP66 |
Rated power |
18W/36W/48W/56W/72W/100W |
Voltage |
100-277 VAC/ 141-392 VDC |
Ambient Temperature |
-20℃-+55℃ |
Luminaire Efficacy |
Up to 140lm/w |
Power factor |
>0.98 |
THD |
<10% |
Weight |
6.9Kg(0.6m)/11.5Kg(1.2m) |
Size |
600*136*124mm(36W/48W/56W)/1200*136*124mm(36W/48W/56W/72W/100W) |
Enclosure |
Copper-free Aluminium |
Color |
grey RAL7040 |
Protective cover |
Tempered glass, stand 7J impact |
Cable Entry |
M20*1.5,M25*1.5,3/4 NPT |
Case study
The Swordfish series consist of 2 sizes : 600*136*124mm(36W/48W/56W)/1200*136*124mm(36W/48W/56W/72W/100W)
, can be widely used for industrial area like Cement plants, Warehouse, Factory, Power Generation, Power Transmission, Shipping industry.
Our Polar Bear installed in Baker hughes(Brunei) Warehouse Lighting Replacement project.
Our sealion installed in Malaysia Petronas-Chemical Ethylene Project provides clear and efficient illumination.
